Dati Tecnici

• Formato: Mini-ITX (170 x 170 mm)
• Chipset: Intel Z890
  Socket: LGA 1851
• RAM:
  2x DDR5
  8400+ MT/s (OC) con XMP
  Max. 64 GB
• Uscite Video:
  1 x HDMI 2.1
  2 x USB4® (40Gbps) con supporto DisplayPort
• Slot Espansione:
  1 x PCIe 5.0 x16 slot
• Storage:
  4x SATA 6G
  2x M.2 PCIe 5.0 x4 slots (Key M)
  1x M.2 PCIe 4.0 x4 slot (Key M)
• Ethernet:
  1x Intel® 2.5Gb Ethernet
• Wireless & Bluetooth:
  Wi-Fi 6E (802.11ax)
  Bluetooth 5.3
• USB:
  Posteriori:
  2 x USB4 (40Gbps) ports (USB Type-C)
  6 x USB 10Gbps ports (Type-A)
  Frontali:
  1 x USB 20Gbps Type-C
  2 x USB 5Gbps headers (supportano 4 porte USB 5Gbps)
  2 x USB 2.0 headers (supportano 4 porte USB 2.0)
• Audio:
  ROG SupremeFX 7.1 Surround Sound High Definition Audio CODEC ALC4082
  DTS® Sound Unbound
• Connettori Back Panel I/O:
  2 x USB4® (40Gbps) ports (USB Type-C®)
  6 x USB 10Gbps ports (Type-A)
  1 x HDMI™ port
  1 x Intel® 2.5Gb Ethernet port
  2 x Gold-plated audio jacks
  1 x Optical S/PDIF out port
  1 x BIOS FlashBack™ button
  1 x Clear CMOS button
• Connettori Interni:
  Fan and Cooling:
  1 x 4-pin CPU Fan header
  1 x 4-pin AIO Pump header
  2 x 4-pin Chassis Fan headers
  Power:
  1 x 24-pin Main Power connector
  1 x 8-pin +12V CPU Power connector
  Storage:
  2 x M.2 slots (Key M)
  4 x SATA 6Gb/s ports
  USB:
  1 x USB 20Gbps connector (supporto USB Type-C®)
  2 x USB 5Gbps headers (supportano 4 porte USB 5Gbps)
  2 x USB 2.0 headers (supportano 4 porte USB 2.0)
  Varie:
  2 x Addressable Gen2 headers
  1 x FlexKey button
  1 x Front Panel Audio header (F_AUDIO)
  1 x 10-1 pin System Panel header
  1 x Thermal Sensor header
