Dati Tecnici:

• Formato: ATX (305 x 244 mm)
• Chipset: AMD X870E
  Socket: AM5
• RAM:
  4x DDR5
  8000+MT/s(OC) with Ryzen
  ECC & Non-ECC Un-buffered DIMM
  ASUS Enhanced Memory Profile (AEMP)
  Max. 192 GB
• Uscite Video:
  1 x HDMI
  1 x DisplayPort
  2 x USB4® (40Gbps) ports support USB Type-C display outputs
• Slot Espansione:
  AMD Ryzen 9000 & 7000:
  1 x PCIe 5.0 x16 slot (supports x16 mode)
  AMD Ryzen™ 8000:
  1 x PCIe 4.0 x16 slot (supports x8/x4 mode)
  AMD X870 Chipset
  1 x PCIe 4.0 x16 slot (supports x4 mode)
• Storage:
  2x SATA 6G
  M.2_1 slot (Key M), type 2242/2260/2280 (supports PCIe 5.0 x4 mode)
  M.2_2 slot (Key M), type 2242/2260/2280/22110 (supports PCIe 5.0 x4 mode)
  M.2_3 slot (Key M), type 2280 (supports PCIe 4.0 x4 mode)
  M.2_4 slot (Key M), type 2280 (supports PCIe 4.0 x4 mode)

• Ethernet:
  1 x Intel 2.5Gb Ethernet
• Wireless & Bluetooth:
  1x Wi-Fi 7, 2x2 Wi-Fi 7 (802.11be)
  1x Bluetooth v5.4
• USB:
  Posteriori:
  2 x USB4® (40Gbps) ports(2 x USB Type-C® with DP Alt mode)
  6 x USB 10Gbps ports (5 x Type-A + 1 x USB Type-C® with up to 30W PD Fast-charge)
  4 x USB 5Gbps ports (4 x Type-A)
  Frontali:
  1 x USB 20Gbps connector (supports USB Type-C®)
  2 x USB 5Gbps headers support 4 additional USB 5Gbps ports
  2 x USB 2.0 headers support 4 additional USB 2.0 ports

• Audio:
  ROG SupremeFX 7.1 Surround Sound High Definition Audio CODEC ALC4080
• Connettori Back Panel I/O:
  2 x USB4® (40Gbps) ports (2 x USB Type-C® with DP Alt mode)
  6 x USB 10Gbps ports (5 x Type-A + 1 x USB Type-C® with up to 30W PD Fast-charge)**
  4 x USB 5Gbps ports (4 x Type-A)
  1 x DisplayPort
  1 x HDMI™ port
  1 x Wi-Fi module
  1 x Intel® 2.5Gb Ethernet
  2 x Audio jacks 
  1 x Optical S/PDIF out port
  1 x BIOS FlashBack™ button 
  1 x Clear CMOS button 
• Connettori Interni:
  Fan and Cooling:
  1 x 4-pin CPU Fan header
  1 x 4-pin CPU OPT Fan header
  1 x 4-pin AIO Pump header
  5 x 4-pin Chassis Fan headers
  Power:
  1 x 24-pin Main Power connector
  2 x 8-pin +12V CPU Power connector
  Storage:
  4 x M.2 slots (Key M)
  2 x SATA 6Gb/s ports
  USB:
  1 x USB 20Gbps connector (supports USB Type-C®)
  2 x USB 5Gbps headers support 4 additional USB 5Gbps ports
  2 x USB 2.0 headers support 4 additional USB 2.0 ports
  Varie:
  3 x Addressable Gen 2 headers
  1 x Alteration PCIe mode switch
  1 x Chassis Intrusion header
  1 x CPU Over voltage jumper
  1 x Front Panel Audio header (F_AUDIO)
  1 x Start button
  1 x 10-1 pin System Panel header
  1 x Thermal Sensor header
